VMC850 CNC Vertical Machining Center with BT40 Sp | RFQ Sourcing Details

The VMC850 is an automatic CNC vertical machining center configured for three-axis milling operations. Its stated X, Y, and Z travels are 800 mm, 500 mm, and 500 mm. The machine uses linear guideways and a BT40 spindle rated for a maximum speed of 8,000 rpm.

Main motor power is listed as 7.5 kW, while rapid traverse rates are 24 m/min on X, 24 m/min on Y, and 20 m/min on Z. The specified cutting-feed range is 1–8,000 mm/min. The technical table specifies a 1,000 × 500 mm worktable with a maximum load of 500 kg and five 18 mm T-slots on 90 mm pitch.

Another part of the supplied information lists the table as 1,050 × 500 mm, so buyers should obtain a confirmed configuration drawing before ordering. The spindle nose-to-table distance is stated as 130–630 mm, and the spindle-axis-to-column distance is 525 mm.

Tool handling is Listed tool limits are 78 mm maximum diameter, or 120 mm where adjacent positions permit, and 8 kg maximum weight. Tool-change time is stated as 2–3 seconds.

The standard description also includes centralized automatic lubrication, chip flushing, air and water guns, an air-storage tank, an electrical-cabinet air conditioner, AirTAC pneumatic components, a BT40 milling chuck, and a tool-locking block. The listed standard control choices are GSK 25i or KND 1000.

Published accuracy figures are 0.0075 mm positioning accuracy and 0.005 mm repeat positioning accuracy. The supplied description states that each machine undergoes Renishaw laser-interferometer and ballbar testing.

Buyers should request the inspection records for the individual machine and agree on the acceptance method, measurement standard, environmental conditions, and test scope. The machine weight is listed as 5,000 kg, while the packaged gross weight is listed as 6,000 kg.

Machine dimensions are stated as 2,600 × 2,300 × 2,800 mm, but separate basic and packaging data contain different dimensions. Confirm the final machine footprint, service clearances, packaged size, lifting points, foundation requirements, and shipment weight before planning installation.

Procurement questions to confirm: verify the exact table size and overall dimensions;select and document the control system;confirm the spindle, magazine, guideway, bearing, and electrical-component brands fitted to the ordered unit;identify which listed features are standard or optional;obtain the electrical, pneumatic, tooling, coolant, and site-preparation requirements;and agree on commissioning, operator training, inspection, delivery, customization, and after-sales arrangements.

An 18-month warranty and customization availability are stated, but buyers should request the written warranty scope, exclusions, start date, and service procedure.
