650 mm Travel 3-Axis Vertical CNC Machining Cente | RFQ Sourcing Details
Cnc Machining Centers · Quote on request
This is a product procurement detail page: check specs, images, category context and related sourcing paths before sending an RFQ.
Quote on requestProduct specs
Buyer's Digest
Use this page as a product-first sourcing checkpoint before sending an RFQ. Category: Cnc Machining Centers. Confirm application fit, capacity, materials, destination, lead time and compliance requirements before comparing suppliers.
Original product description
Product overview This vertical CNC machining center is specified with X/Y/Z travels of 650 × 400 × 500 mm and a spindle-nose-to-table range of 100–600 mm. The worktable measures 900 × 360 mm and has a stated maximum load of 500 kg. Its listed machining functions include milling, drilling, boring, reaming, and tapping.
Stated machine configuration The specification table identifies a BT40 spindle taper, 8,000 rpm spindle speed, 5.5 kW main motor, three servo-driven axes, rigid tapping, a portable handwheel, and a 16-tool changer.
The table also states X/Y rapid feed of 28,000 mm/min, Z rapid feed of 14,000 mm/min, and cutting feed of 1–10,000 mm/min. Linear guideways and a 10,000 rpm spindle are described as available options rather than confirmed standard equipment.
Accuracy figures supplied for the listed configuration are ±0.006 mm positioning accuracy and ±0.003 mm per 300 mm repeatability. A separate basic-information field gives processing precision as 0.01–0.02 mm.
Buyers should define the applicable test method, machine condition, warm-up procedure, measurement standard, and acceptance document before treating these figures as contractual requirements.
Customization and procurement questions OEM and ODM customization are listed as available, including customized color, voltage, logo, spindle specification, and selected components.
Controller information is not fully consistent: the parameter table lists KND, while other fields mention GSK, Siemens, Fanuc, Mitsubishi, and Syntec as possible systems.
Confirm the exact controller brand and model, included software functions, electrical standard, axis configuration, tool changer, spindle speed, guideway type, and component brands in the final quotation. The machine is listed as new and supplied in plywood packing.
Machine size is stated as 2,500 × 2,250 × 2,250 mm, machine weight as 3 tonnes, and packed shipment data as 232 × 228 × 250 cm with a gross weight of 4,200 kg.
Buyers should reconcile these installation and shipping figures, then confirm foundation requirements, doorway clearance, unloading method, air supply, electrical input, commissioning scope, operator training, spare parts, delivery schedule, warranty coverage, and after-sales service terms before purchase.
650 | Applications and Buyer Notes
650 is organized as a sourcing-ready Cnc Machining Centers reference. The page combines visible product or company data with structured procurement cues so buyers can compare application fit, specifications, quantity, quality requirements and lead-time questio
Applications
- Initial shortlist building for related product or supplier options.
- Specification and application fit review before bulk purchasing.
- Category, keyword and detail-page comparison before sending an RFQ.
Key specifications
- Category
- CNC Machining CentersBased on visible page data; confirm exact value in the RFQ.
- Unit
- setBased on visible page data; confirm exact value in the RFQ.
- T-slots
- 3 slots, 14 mm widthBased on visible page data; confirm exact value in the RFQ.
- Main motor
- 5.5 kWBased on visible page data; confirm exact value in the RFQ.
- Rapid feed
- X/Y: 28,000 mm/min;Z: 14,000 mm/minBased on visible page data; confirm exact value in the RFQ.
- Table size
- 900 × 360 mmBased on visible page data; confirm exact value in the RFQ.
- Cutting feed
- 1–10,000 mm/minBased on visible page data; confirm exact value in the RFQ.
- Tool changer
- 16 t sBased on visible page data; confirm exact value in the RFQ.
Buyer tips
- State quantity range and split-delivery needs before price comparison.
- Add certification, material or inspection standards when they affect acceptance.
- For time-sensitive projects, include target arrival date and destination.
- For special applications, describe operating condition, installation environment and duty cycle.
FAQ
What should buyers confirm first?
Confirm application, specification, quantity, destination and lead-time requirements before comparing offers.
Can buyers inquire when specs are incomplete?
Yes. Add model, material, size, use case and inspection needs in the RFQ to make replies comparable.
How should this listing be evaluated?
Check title, category, specifications and related keywords against the actual sourcing requirement.
Source mix: ugc
Key specifications
Product sourcing keywords
These terms come from the title, visible copy and specifications, and link into matching aggregate pages.
Continue from this detail page into sourcing structure
These links connect the detail page back to category hubs, procurement aggregates and knowledge pages so new inventory is not isolated.
This URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path Cnc Machining Centers categoryThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path Cnc Lathes And Turning categoryThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path Milling Drilling And Grinding categoryThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path Tooling Fixtures And Accessories categoryThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path Procurement sourcing pathThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path Cnc Machine Suppliers sourcing pathThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path 10 Off Good Quality Vertical Machining Center Vmc850 3 Axis Cnc Vertical Machining Center For SaleThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path Cnc Lathe Exporters sourcing pathThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path Machining Center Manufacturers sourcing pathThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path CompanyThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path 3 4 Axis Small Cnc Milling Machine Vmc850 Vertical Machining Center Cnc Vertical Machining CenterThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path 3 Axis Large High Perform Cnc Controller Vertical Milling Machining Center Vmc960This URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path 3 Axis Vmc215 Small Mini Cnc Milling Machine Vertical Machining Center Cnc Vertical Machining CentThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
VMC650 3-Axis Vertical CNC Machining Center with BT40 Spindle and 24-Tool MagazineRequest Quote
VMC650 3-Axis CNC Vertical Machining Center with 900 × 400 mm TableRequest Quote
VMC650 3-Axis Vertical CNC Machining Center with BT40 SpindleRequest Quote
VMC1160 4-Axis BT40 Vertical CNC Machining Center with 1100 × 600 × 600 mm TravelRequest Quote
LJ-1165 CNC Vertical Machining Center, 1100 × 650 × 600 mm TravelRequest Quote
T1000 Compact 3/4/5-Axis CNC Vertical Machining Center with 1000 × 500 × 450 mm TravelRequest QuoteCNCMillHub related sourcing paths
