TIMAC G Series Hard-Guide Gantry CNC Machining Ce | RFQ Sourcing Details

The TIMAC G Series is a fixed-gantry, moving-table CNC machining center designed for milling, boring, drilling, tapping and sinking. Listed models include G-3016, G-3516, G-3522, G-4522, G-4526, G-6526, G-6530, G-8530, G-6536, G-8536 and G-10536.

The series uses a closed gantry frame formed by the bed, columns and beam. Supported configuration details Depending on the model, the table is listed from 2500 × 1200 mm to 10000 × 3000 mm, X-axis travel from 3000 to 10500 mm, Y-axis travel from 1800 to 3800 mm, and standard Z-axis travel from 1000 to 1250 mm.

Parenthetical Z-axis options extend to 1250 or 1500 mm on specified configurations. Maximum listed table load ranges from 6000 to 100000 kg. The stated standard spindle is a direct-connected BT50 unit operating at 3000 rpm. Selected larger models list BT60 as an alternative.

Main-motor ratings vary by configuration, while the automatic tool-magazine options are 24, 32 or 40 tools. Listed rapid traverse is 10 m/min on all three axes, and cutting-feed speed is 5–8000 mm/min. The structure uses high-strength inoculated cast iron, resin-bonded sand casting and multiple aging treatments.

The hard-guide surfaces are high-frequency quenched, with a stated hardness of HRC 45. The X axis can optionally use a constant-flow static-pressure guide. An accessory milling head can support five-face machining in one clamping.

The specification table states semi-closed-loop positioning accuracy of 0.012 mm and repeat positioning accuracy of 0.008 mm for the X, Y and Z axes. These values should be tied to the selected model, control configuration, acceptance method and operating conditions before purchase.

Standard equipment is listed as including a FANUC CNC system, two-sided screw-type chip removal, a two-stage spindle speed-change gearbox, electrical-cabinet air conditioning, air filtration, spindle oil cooling, a cooling device, hydraulic system, protective enclosure, lighting, three-color alarm light, communication interface and handheld electronic handwheel.

Siemens CNC, alternative 6000 rpm spindle arrangements, rotary tables, grating scales and several accessory-head configurations are listed as options.

Procurement questions to confirm Before ordering, obtain a model-specific technical schedule that identifies the exact table dimensions, travels, column clearance, allowable load, spindle type, motor rating, torque, guideway arrangement, tool magazine and machine footprint.

Confirm whether every parenthetical value is an included feature or a priced option. Buyers should also define the required CNC system, electrical voltage and capacity, accessory-head functions, rotary-table requirements, coolant and chip-management configuration, and any column-height or Z-travel changes.

Request written acceptance criteria for positioning and repeatability, including the applicable test standard, measurement conditions and whether full closed-loop feedback or grating scales are required.

Installation planning should cover foundation loads, machine weight, access and lifting requirements, air supply, electrical service and available floor space.

Finally, confirm the exact CE and ISO 9001 documentation supplied with the ordered machine, as well as the agreed warranty, spare-parts, commissioning, training, service, delivery and packaging terms.
