VMC650 Vertical CNC Machining Center with 900 × 4 | RFQ Sourcing Details

The VMC650 is a vertical CNC machining center configured for metal-cutting operations such as drilling, hole expansion, reaming, tapping, face and step milling, groove milling, bevel-edge work, and machining curves, curved surfaces, and cams.

Its specified working envelope includes X/Y/Z travels of 650 × 450 × 510 mm and a 900 × 400 mm worktable rated for loads up to 500 kg. The machine uses linear guideways on all three axes and a BT40 spindle taper. The listed standard maximum spindle speed is 8,000 rpm, with 10,000 rpm identified as an option.

Rapid traverse is specified at 36 m/min on each axis, while cutting feed is listed from 1 to 10,000 mm/min. The main motor is specified at 5.5 kW;another summary field also lists a 5.5/7.5 kW selection, so the installed motor should be confirmed for the ordered configuration.

Accuracy data in the detailed specification lists positioning accuracy of ±0.0075 mm and repeat positioning accuracy of ±0.005 mm. A separate overview states positioning accuracy of ±0.008 mm.

Buyers should therefore obtain an agreed inspection standard, test method, and acceptance report for the exact machine before ordering. The worktable has three T-slots specified as 14 mm wide on 80 mm pitch.

The detailed specification lists a 16-tool armless magazine for the VMC650, while the product information also describes 16-, 20-, and 24-tool arm-type options. Maximum tool diameter and tool weight are listed as 90 mm and 8 kg.

The standard controller is identified as GSK, with Siemens, Fanuc, and Syntec presented as optional controller choices. Listed standard equipment includes an arm tool magazine, NSK bearings, an R+W coupling, automatic lubrication, air cooling, a cooling system, and sizing blocks.

Available options include a CNC dividing head, NC rotary table, automatic chip conveyor, fourth axis, and bar feeder. Because the tool-magazine descriptions differ between sections, the final equipment schedule should identify the exact magazine type and capacity. The machine is listed at approxima 800 kg.

Customer-selected voltage, color, and logo are listed as available customization items. Video technical support and a one-year warranty are stated.

Before procurement, confirm the electrical standard, controller and software package, spindle speed and motor rating, tool-magazine design, included accessories, optional-axis integration, coolant and chip-management equipment, accuracy acceptance procedure, installation requirements, commissioning scope, documentation, spare-parts package, shipping configuration, and warranty coverage in the final order specification.
