VMC1050 Heavy-Duty CNC Vertical Machining Center | RFQ Sourcing Details

The VMC1050 is a heavy-duty CNC vertical machining center intended for mechanical processing and mold making. Its stated process range covers rough through finish machining and operations including milling, drilling, tapping, and boring.

The machine is specified with a 1000 × 500 mm worktable, 1000 mm X-axis travel, 500 mm Y-axis travel, and a maximum table load of 500 kg.

The detailed technical table states 500 mm Z-axis travel, while another source section states 550 mm;buyers should obtain a signed configuration sheet confirming the supplied Z travel before ordering. The table has five 18 mm T-slots on 90 mm pitch.

The BT40 spindle is rated for up to 8000 rpm and is paired with a 7.5 kW main motor. Listed feed data includes 24/24/20 m/min rapid traverse for the X/Y/Z axes and a cutting-feed range of 1–8000 mm/min.

The machine uses linear guideways and has stated positioning accuracy of 0.0075 mm and repeat positioning accuracy of 0.005 mm. Tool handling is The listed maximum tool diameter is 78 mm, or 120 mm under the applicable adjacent-tool condition, and maximum tool weight is 8 kg.

The source also states a 2–3 second tool-change time;buyers should confirm the measurement method and supplied magazine configuration.

Standard equipment described for this model includes an automatic centralized lubrication system, chip flushing, air and water guns, pneumatic components, an air storage tank, an electrical-cabinet air conditioner, a BT40 milling chuck, and a tool-locking block. A chip conveyor is identified as optional.

Standard controller choices are listed as GSK 25i or KND 1000. The stated machine construction uses HT300 cast iron. Listed component details include a Taiwan-origin BT40 spindle, HIWIN lead screw, SKF or NACHI lead-screw bearings, YC direct coupling, and HIWIN or PMI roller linear guideways.

Schneider safety electrical components and AirTAC pneumatic components are also described. Each machine is stated to undergo Renishaw laser-interferometer and ballbar testing. The detailed specification lists a machine weight of 5200 kg and overall dimensions of 3200 × 2400 × 2800 mm.

Packaging information separa mation: request the final controller, Z-axis travel, spindle and guideway brands, tool-magazine arrangement, electrical voltage and frequency, included tooling, optional chip conveyor status, accuracy inspection report, applicable certification documents, foundation requirements, commissioning scope, delivery schedule, and after-sales terms in the purchase contract.

Customization and an 18-month warranty are stated, but coverage, exclusions, response times, and service responsibilities should be confirmed in writing.
