Main Features Goo. Da Heavy-duty Horizontal Machining Center WJ-1390/1815/2015/2515 series, a paragon of robust design centered around heavy-duty machining. This series elevates your production capabilities with enhanced functions for heavy cutting, substantial load endurance, and proficient roughing.

Achieve superior results in machining mold bases and frames with remarkable efficiency. This machine excels in cavity roughing, intricate surface finishing, and deep cavity machining, dramatically boosting operational productivity. 1.

Designed with an innovative inverted T-type machine bed, complemented by a vertically-mounted spindle head, ensuring steadfast spindle rigidity even as the column moves, enhancing overall precision. 2.

Heavy-duty cutting is redefined with a robust spindle, boasting an outer diameter of Φ220mm, offering exceptional cutting rigidity for the most demanding applications. 3. The extended spindle sleeve nose, stretching 450mm, significantly boosts deep cavity cutting prowess, enabling complex operations with ease.

Core Components Bed & Base Experience unmatched rigidity and stability with the inverted 'T' type bed structure. It remarkably mitigates machine vibrations, prolonging tool life and ensuring smooth operation. Head Dual extended heavy-duty 55# roller linear guides provide exceptional vibration resistance.

The spindle box, enhanced with a nitrogen balance system, boosts dynamic response speed for superior performance. Spindle With an increased spindle sleeve diameter, cutting rigidity is optimized. Experience spindle RPMs reaching up to 3000rpm/6000rpm, supported by a cooling system for unwavering long-term stability.

Z-axis The Z-axis movement encompasses the full range of the column, maintaining consistent rigidity of both the Z-axis and spindle head, significantly reducing tool vibration during intricate deep cavity machining.

Protection Cover Enhance safety and security with the machine's semi-enclosed protective cover, ensuring a safer working environment.

Column The Y-axis features a dual-layer wall moving column structure, crafted from premium HT-300 cast iron with secondary annealing, guaranteeing resistance to deformation, superior accuracy, stability, and extended service life.

Our dedicated team of experts is on standby to guide you in selecting the machine that perfectly aligns with your processing demands. Receive Professional Guidance Today!

Product Parameters Model WJ-1390 Category Attribute Value Unit Worktable Worktable size 1000×1360 (optional 630×630/800×800 rotary table) mm Max.load capacity 5000 kg T-slot size 4-22×200 mm Travel X axis travel 1300 mm Y axis travel 900(or 1500) mm Z axis travel 700(or 850) mm Min.

distance from spindle center to table 150 mm Min.

distance from spindle face to table center 300 mm Spindle Spindle taper BT50/Φ220 - Spindle motor power 15/18.5(optional 22/26) Kw Spindle Max.speed 2500/4000/6000 rpm Feed X/Y/Z axis rapid move speed 12/12/12 m/min Tool magazine Tool capacity 24T(or 32T) T Accuracy Positioning accuracy 0.02/1000 mm Others Total power required 50 KVA Machine size 3.9×5.1×3.6 m Machine weight (approx.) 12 T
